What is Stainless steel connector elbow joint?
It functions to connect two sections of the pipe at a 90-degree angle to change the direction of flow within the pipe system.
Application scope: food industry, chemical industry, pharmaceutical industry, navy industry and construction industry.
Technical data sheet:
● Body and push button made entirely of AISI 316L stainless steel.
● Gasket in VITON (FKM).
● Suitable for aggressive fluids and environments and the food industry.
● Working pressures: -1 / 15 bar (at 20ºC).
● Working temperatures: -20 – 160ºC.
● Long service life.
01 Part name
Stainless steel elbow joint
02 Application
Industries components
03 Material
Stainless steel
04 Process
Investment casting
& Machining
05 Casting method
Thermal Gravity Casting
06 Surface finished
Shot blasting
Part Application
Investment casting, also known as lost-wax casting, is a manufacturing process used to create metal parts with complex shapes and intricate details
Available Material
|
1-Carbon steel |
2-Low alloy steel |
3-Corrosion-resistant steel |
4-Heat-resistant steel |
||||
|
General engineering cast steel (ISO 3755) |
Carbon and low alloy cast steels for general applications (ISO 14737) |
Corrosion-resistant cast steels for general applications (ISO 11972) |
Heat-resistant cast steels and alloys for general applications (ISO 11973) |
||||
|
200-400 |
400-550MPa |
GE200 |
1.0420 |
GX12Cr12 |
1.4011 |
GX30CrSi7 |
1.4710 |
|
200-400W |
400-550MPa |
GE240 |
1.0446 |
GX2CrNi19-11 |
1.4309 |
GX40CrSi13 |
1.4720 |
|
230-450 |
450-600MPa |
GS340 |
1.0467 |
GX5CrNi19-10 |
1.4308 |
GX40CrSi17 |
1.4740 |
|
230-450W |
450-600MPa |
G20Mo5 |
1.5419 |
GX5CrNiMoNb19-11-2 |
1.4581 |
GX40CrSi24 |
1.4745 |
|
270-480 |
480-650MPa |
G42CrMo4 |
1.7231 |
GX5CrNiMoN19-11-3 |
1.4412 |
GX25CrNiSi18-9 |
1.4825 |
|
270-480W |
480-650MPa |
G28Mn6 |
1.1165 |
GX2NiCrMoCuN25-20-6 |
1.4588 |
GX40CrNiSi25-12 |
1.4837 |
|
340-550 |
550-720MPa |
G26CrMo4 |
1.7221 |
GX5CrNiMoCuN 26-6-3 |
1.4515 |
GX40CrNiSi25-20 |
1.4848 |
Production Process Introduce
RFQ handle process
You can find our contact info for further communication in “Contact US” column.
The 2&3D drawing format can be PDF, STEP, DWG, DXF and soon, can be sent via email. Wechat, WhatsApp, link.
After clear the demand of customer, we can send you the quotation with PDF format for documentation.
For requirements for confidentiality of drawings, we can signed the NDA before you send drawing.
The feasibility study of drawing is most key point to ensure the part can be fully meet drawing specifications, which is include material, dimension, surface treatment, and testing request.
Product Advantages
Inconel alloys exhibit exceptional durability and heat resistance, rendering them ideal for use in turbochargers exposed to exhaust gases up to 800°C. Due to the challenging machinability of Inconel alloys, precise tolerances are cast in advance wherever feasible, minimizing or eliminating the need for mechanical post-processing steps.
